Permanent N40SH Wind turbine magnet

Share to:

Quantity:



Inquire Add to Basket

Model:
N33-N52,30M-50M,30H-48H,28SH-45SH,28UH-42UH,28EH-38EH,28AH-33AH
Standard:
N40-N52,30M-50M,30H-48H,28SH-45SH,28UH-42UH,28EH-38EH,28AH-33AH
Trademark:
Super
Productivity:
150 longton/month
Origin:
Anhui,China
Packing:
Standard Export Carton
Unit:
piece/N40SH ndfeb magnet rings
Max order:
150 longton/month
Min order:
1 N40SH ndfeb magnet rings
TransTime:
5 days after deposit
Transportation:
1
Payment:
T/T

ring magnets

Product Name: Neodymium Ring Magnet/NdFeB Ring Magnet/Permannt Neodymium ring magnets

Applications: NdFeB Ring magnets are Widely used in different applications, such as sensors, motors,
rotors, wind turbines/wind generators, loudspeakers, magnetic hooks, magnetic holder,
filters automobiles and so on.

Material: NdFeB (Neodymium Iron Boron)

Shape: Ring (Customized shapes for Sintered NdFeB Magnet are available.)

Tolerance in size: +/-0.05mm or +/-0.1mm

Type of coating: Ni-Cu-Ni, Nickel, Zn, Gold, Silver, Copper, Epoxy, Chemical, PTFE, Parylene,
Everlube, Passivation and more.

Grade: N35-N52; N33M-N50M; N33H-N48H; N30SH-N45SH;N30UH-N40UH; N28EH-N38EH,N28AH-N35AH.

Product:	N40SH ndfeb magnet rings
Material:	Neodymium-Iron-Boron
Coating:	Nickel, Zn, Black Epoxy, Black Nickel , Nickel -Cu-Nickel, Ag, Au etc.
Size	We have various common size, special size can be design and made as your request
Features:	High remanence, high coercive force, high energy High resistance to magnetic demagnetization High temperature resistance, corrosion resistance
Applicatios:	Used in many fields, such as motors, sensors, microphones, wind turbines, wind generators, VCMs in hard disk drives, printer, switchboard, loudspeakers, magnetic separation, magnetic hooks, magnetic holder, magnetic chuck, common daily use, and so on.
Delivery:	By sea, By air, By Express, various ways can be selected. We also cooperate with famous express companies like DHL, FedEx, EMS, TNT, UPS and so on. Our lead time is always quicker than average.
Magnetic Performance
Grade	Remanence Br mT (kGs)	Coercive force HcB KA/m (KOe)	Magnetic energy product Max KJ/m³ MGOe	Max.working temperature
N35-N52	1180-1440	836-923	263-406	80°C (176°F)
(11.8-14.4)	(10.8-11.6)	(33-51)
30M-50M	1080-1420	796-1050	223-390	100°C (212°F)
(10.8-14.2)	(10-13.2)	(28-49)
30H-48H	1080-1380	796-1027	223-366	120°C (248°F)
(10.8-13.8)	(10-12.6)	(28-46)
28SH-45SH	1050-1340	764-995	207-342	150°C (302°F)
(10.5-13.4)	(9.6-12)	(26-43)
28UH-42UH	1050-1310	764-923	207-326	180°C (356°F)
(10.5-13.1)	(9.6-11.6)	(26-41)
28EH-38EH	1050-1250	764-868	207-295	200°C (392°F)
(10.5-12.5)	(9.6-10.9)	(26-37)
28AH-33AH	1020-1170	780-836	199-271	220°C (428°F)

Product:	N40SH ndfeb magnet rings
Material:	Neodymium-Iron-Boron
Coating:	Nickel, Zn, Black Epoxy, Black Nickel , Nickel -Cu-Nickel, Ag, Au etc.
Size	We have various common size, special size can be design and made as your request
Features:	High remanence, high coercive force, high energy High resistance to magnetic demagnetization High temperature resistance, corrosion resistance
Applicatios:	Used in many fields, such as motors, sensors, microphones, wind turbines, wind generators, VCMs in hard disk drives, printer, switchboard, loudspeakers, magnetic separation, magnetic hooks, magnetic holder, magnetic chuck, common daily use, and so on.
Delivery:	By sea, By air, By Express, various ways can be selected. We also cooperate with famous express companies like DHL, FedEx, EMS, TNT, UPS and so on. Our lead time is always quicker than average.
Magnetic Performance
Grade	Remanence Br mT (kGs)	Coercive force HcB KA/m (KOe)	Magnetic energy product Max KJ/m³ MGOe	Max.working temperature
N35-N52	1180-1440	836-923	263-406	80°C (176°F)
(11.8-14.4)	(10.8-11.6)	(33-51)
30M-50M	1080-1420	796-1050	223-390	100°C (212°F)
(10.8-14.2)	(10-13.2)	(28-49)
30H-48H	1080-1380	796-1027	223-366	120°C (248°F)
(10.8-13.8)	(10-12.6)	(28-46)
28SH-45SH	1050-1340	764-995	207-342	150°C (302°F)
(10.5-13.4)	(9.6-12)	(26-43)
28UH-42UH	1050-1310	764-923	207-326	180°C (356°F)
(10.5-13.1)	(9.6-11.6)	(26-41)
28EH-38EH	1050-1250	764-868	207-295	200°C (392°F)
(10.5-12.5)	(9.6-10.9)	(26-37)
28AH-33AH	1020-1170	780-836	199-271	220°C (428°F)

Wind turbine magnet Neodymium ring magnetsmagnet N40SH ndfeb magnet rings Permanent N40SH magnet rings
